TD-9585C4-A(PE/WR2)
TVT 8MP Full Colour Intelligent IP Camera-2.8mm
8M Pixel, 24/7 colorful imaging, POE, White Colour, 2.8mm Fixed Lens, F1.0 Large Aperture, 1/1.8″ CMOS Sensor, Built-in MIC, Built-in Micro SD Card Slot, Vandalproof, IP 67, ONVIF, 3-Axis, 24/7 Full Colour, People and Vehicle Detection, Intelligent Analytics
 |
24/7 Full Colour Night Vision |
 |
People and Vehicle Detection |
 |
Intelligence Analytics |
Features:
- H.265+ / H.265 / H.264 +/H.264 / MJPEG coding
- Max. resolution: 3840 × 2160
- 20~ 30m white light view distance
- 24/7 full color imaging
- 3D DNR, HLC, BLC, and ROI coding
- Support electronic image stabilization
- Support image distortion correction
- Support 1CH audio input; 1 CH built-in MIC
- Built-in micro SD card slot; up to 1TB
- DC12V/PoE power supply
- IP 67 ingress protection
- Support three streams
- Support remote monitoring by smart phones & tablet PCs with iOS and Android OS
- Multiple smart events can be enabled at the same time
- Support P2P function
- Support dual-system backup
| Camera | |
| Image Sensor | 1 / 1.8" CMOS |
| Image Size | 3840 × 2160 |
| Lens | 2.8mm Fixed Lens |
| Image | |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Resolution | 8MP (3840×2160),6MP (3200×1800),4MP (2688×1520),2K (2560×1440), 1080P (1920×1080), 720P (1280×720 ), D1, VGA (640 ×480), 640 ×360, CIF, 480×240 |
| Bit Rate | 32 Kbps ~ 12Mbps |
| Bit Rate Type | VBR / CBR |
| Audio Compression | G711A/U |
| Interfaces | |
| Network | RJ45 |
| Audio | 1CH audio input; 1 CH built-in MIC |
| Storage | Built-in micro SD card slot, up to 1TB |
| Reset | Yes |
| Functions | |
| Network Protocol | UDP, IPv4, IPv6, DHCP, NTP, RTSP, RTP, RTCP, RTMP, FTP, PPPoE, DDNS, SMTP, SNMP, HTTP, 802.1x, UPnP, HTTPS, HTTP POST, P2P, QoS |
| Standard protocol | Onvif |
| Smart Alarm | Motion detection, SMD, SD card error, SD card full, IP address conflict, Network disconnection |
| Smart Event | Line crossing, region intrusion/entrance/exiting (human/vehicle classification), abandoned/ missing object detection |
| PoE | Yes (IEEE802.3af) |
| White light range | 20 ~ 30 m |
| Ingress Protection | IP67 |
| Other | |
| Power | POE / DC 12V |
| Power Consumption | < 7.5W |
| Dimension | 111.6(Ø) X 99.6(D) mm |
